Kay Jay Forgings Pvt. Ltd.

Infrastructure >> CAD - CAM

We use the latest CAD software in our design center and as a result our engineers have been able to improve component benefits and interchangeability, thereby enhancing the effectiveness, quality and ergonomic. CAD - CAM 3D design software Solid Works and Espirit allow our experienced forging designers and apprenticed diesinkers to quickly go from yours files to steel, shortening the "Print to Part" lead time.

Deckel Maho 70V vertical machining center with automatic tool changer having carousel magazine with 30 packets, minimizing the tool changing time. With 18000 spindle RPM which turn give high surface finish on dies and a feed of 70 meters per minute.

Wire Cut Electronica Omnicut wire cut machine with cutting speed of 80mm square per minute equipped with LM guides and hand held remote controls.

CNC Vertical Machining Center TONG TAI'S TOPPER make CNC vertical machining centre with 24 stations ATC with hydraulic clamping, FANUC conroller. Work table size 850 mm x 470 mm with XYZ travel of 760mm x 450mm x 530mm to machine any type of forging die or production component involving multi tooling in one setting.
